Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller

    Buy cheap Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller from wholesalers

    Buy cheap Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller from wholesalers
    • Buy cheap Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller from wholesalers
    • Buy cheap Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller from wholesalers
    • Buy cheap Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller from wholesalers

    Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller

    Ask Lasest Price
    Brand Name : BJJCZ
    Model Number : Yb-001
    Certification : CE
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 sets
    Delivery Time : 5 working days
    • Product Details
    • Company Profile

    Economic CO2 Laser Controller Board , V4 Ezcard 1064 Nm CNC Laser Controller

    JCZ Laser Marking Board Controller Simple Economic Card V4 Ezcard 1064nm
    Product Details

    JCZ simplified English version fiber marking control card laser marking control board for laser marking machine

    Fiber marking control card enables real-time control of scan system and lasers over a standard USB host interface. Customers can integrate complete machinery easily over the EzCad Card due to its compactness and I/O capabilities. Fast response times and short execution cycle times make the EzCad Card perfectly suitable for high performance applications. It can load marking file via a removable MMC memory card.


    V4 Lite Card Parameter
    BrandJCZ
    Laser SourceCO2/YAG/Fiber/UV Lase
    ConnectionUSB 2.0
    Laser SignalDB25 connector output laser signal
    Scanner SignalDigital signal , can directly connect to common international digital signal
    Input IO16 routes TTL
    Output IO14 routes TTL
    ReMark SIgnalCached content repeat marking
    Expand Axis2 expand axis
    Fly markingSupport
    MultiheadSupport
    Custom SoftwareOptional
    Rotary MarkingYes
    PowerDC 5V 3A

    Specifications

    USB 2.0 micro controller on board:


    128 Kbyte program and data memory


    64 Kbyte SRAM for USB data buffering

    Real-time calculation of laser and scanner signals

    Online grid correction with 10 us cycle time

    MMC memory card interface


    Product Parameters

    Laser Control:
    Laser signals for YAG FIBER and CO2 laser types
    opt coupler TTL Level /10 mA output current
    2 x 8-bit analog channels with 2.5, 5, 10 V output range
    1 x 8-bit TTL output port


    Scanner Control:
    X, Y channel
    XY2-100 digital interface


    Response Times:
    The card can response external trigger with in 12ms
    External trigger delay can be adjusted


    I/O Port:

    6 Input Port
    6 Output Port


    Power:
    +5V/1.5A or +12/0.6A


    Why Choose Us

    We’re professional laser marking machines manufacturer. We’re more familiar with customer’s marking or engraving application so we’re in a position to recommend a more suitable model to customers.

    What’s MOQ?
    One piece. You can mix it with other laser machine parts freely.

    What’s delivery time?
    We have them in stock. We can ship it immediately after receive payment.

    What’s your payment terms?
    T/T, western union, Paypal


    Pre-Sales Service

    * Inquiry and consulting support.
    * Sample testing support.
    * View our Factory.


    After-Sales Service

    * Training how to instal the machine, training how to use the machine.
    * Engineers available to service machinery overseas.


    Packing & Delivery

    size: 25 mm (L) * 20 mm (W) * 150 mm (D)

    Weight: 2kgs

    Packaging Details: The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
